6m Width Used In India Wire Chain Link Fence Netting Machine
Chain Link Fence Netting Machine Description
The chain link fence netting machine is controlled by PLC automatic control system with visual touch screen, so one worker can operated several chain link fence netting machine.The chain link fence netting is flexible and soft, corrosion and rust resistance surface, architectural colors, and easy installation.So the chain link fence netting machine is popular in India.
Chain Link Fence Netting Machine Technology
The chain link fence netting is diamond hole.Diamond hole size of the fence netting is made by different mould dies.It can reduce the wear of iron wire by adding soap to the mold when forming.The machine uses sever motor to feeding wire,common motor in automatic locking device,automatic roll netting device.This chain link fence netting machine don't have welding transformer,only motors.So the machine requires very low power supply
Chain Link Fence Machine Parameter
| Item | Single wire fully automatic chain link fence netting machine |
| Wire Dia. | 1.5-5.0mm |
| Hole Size | 25*25mm-120*120mm |
| Material | galvanized wire, pvc wire |
| Width | 2m | 3m | 4m |
| Capacity | 20-130M2/h |
| Power | 3.8kw/h |
| Mould | 4 sets mould for free |
| Size (L*W*H) | 3.8*3.2*1.5M | 4.8*3.2*1.5M | 5.8*3.2*1.5M |
| Weight | 1.7T | 1.8T | 1.9T |
| Warranty | One year |
| Operation | One person control 2 machines |
Chain Link Fence Netting Machine Packaging and shipping
1. One 20 foot container can hold two machines.The machine is nude packing in the container,it will be fixed in the container by steel wire rope to make it stable.
2. After receiving 30% advance payment, we arrange production.It takes 5 days to produce, and then deliver.
3. Port of shipment Tianjin Port
Afer-sales service
Free spare parts; Online support; Video technical support; Field installation, commissioning and training; Field maintenance and repair service.
Double Wire Spiral Chain Link Fence Netting Machine
Wire Pay-off
Mesh Compressor: The volume of the curled Crochet net becomes smaller after being compressed by the machine.
